HUNTING FOR WASTED COMPUTING POWER
New Software for Computing Networks Puts Idle PC's to Work


by Scott Fields
1993 Research Sampler
University of Wisconsin-Madison

Scattered throughout the world of science are personal computers just waiting to work. While a university biologist grades papers, her computer sits unused. On the desk of an engineering professor, a neglected workstation hums quietly through the night. Idle computers mean wasted computing power. And Miron Livny, a University of Wisconsin-Madison associate professor of computer sciences, hates waste.

Rather than see computers lie fallow, a group of computer scientists now led by Livny has been developing Condor, a software system that puts inactive computers back to work. Like a vulture circling the desert, Condor scavenges for processing power that would otherwise be lost.

The idea behind Condor is simple. It matches any computational jobs that computer users have with spare power in other owners' computers. Computer owners don't have to modify their programs to use Condor. They just have to agree to become part of a Condor network, a group of computers connected in such a way that messages can pass between them.

Condor lurks in the background of the network, nesting in a computer called the central manager-which can be any computer in the network-where it watches for inactive computers. When it senses an idle machine, Condor swoops in to run a project on it. When the owner resumes using the computer, Condor moves the project somewhere else.

In practice, however, Condor is more complicated. Every computer in the pool must continually run parts of the Condor software that track activity on both the central manager and the local system. To do this, the computer must be capable of "multi-tasking," or running more than one piece of software simultaneously, the computer equivalent of walking and chewing gum at the same time.

Currently Condor runs only on workstations that use an operating system called UNIX. This operating system-the software that lets a computer run other software applications-was selected because it can smoothly handle many applications at once and because it is wide- spread in the scientific community. Livny says, however, that Condor could be modified to work with any multi-tasking operating system.

HATCHING AN IDEA

Just a year after Livny arrived at the university in 1984, a team of UW-Madison computer scientists-then including professors David DeWitt and Marvin Solomon-began the Condor project. Livny had started thinking about how to exploit wasted processing power even earlier, when he was a graduate student at the Weizmann Institute in his native Israel.

At that time, he says, the rapid development of mini-computers marked a great shift in where computing power was located. Instead of being concentrated in a single mainframe computer, an institution's computing power was now "distributed" into many small computers. Livny soon realized that this shift would result in wasted computing capacity unless some way were found to harness that power.

Before personal computers became commonplace, Livny explains, scientists shared mainframe computers-often experiencing long delays as the computer processed jobs submitted ahead of theirs. But these centralized systems, although frustrating to use, maximized a computer's processing power, because they ran 24 hours a day.

Personal computers eliminated the wait. But, Livny says, while the recent explosion in personal computing has tremendously increased the amount of computing power-which computer scientists measure in number of computing "cycles"-that researchers own, there has not been a proportionate increase in the number of cycles available to any individual researcher.

"Ten years ago, what was owned and what was accessible were almost the same," Livny says. "Now, because of distributed ownership, there is an increasing gap between what is owned and what is available for scientific computing. What we are trying to do is narrow this gap."

MAKING IT FLY

Developing and debugging Condor's programming code took countless hours of work by a team of UW-Madison programmers headed by Michael Litzkow. But the hardest task for Condor's developers, Livny says, was figuring out how to maintain a comfortable relationship between two communities of computer users: the people who own computers but don't necessarily need more computing power, and people who want to borrow spare cycles. Satisfying both groups was important, he explains, because administrators can't add a machine to the pool without its owner's permission. "So if the owner is not happy," Livny says, "we lose the machine."

Meeting the varied demands of computer owners, however, is not so easy. Condor must keep track of activity on every computer on networks that can include hundreds of computers. It must know how soon it is allowed to start using a computer after the owner stops using it. It must work both in environments where each individual uses just a single computer and in environments where any individual can log on to any computer. And it must know how to share the resources of the network fairly.

Some researchers-Livny calls them "cycle monsters"-have an insatiable appetite for computer cycles. Most of these "frustrated" owners are willing to sacrifice some convenience for a chance to tap into the ocean of computer power a Condor pool offers.

Many other researchers, however, rarely need more cycles than their own computers offer. These scientists are often reluctant to join the Condor pool, since they think they have little to gain from it. "These `happy' or `almost-always-happy' owners are the ones that we have to convince," Livny says.

To lure them to Condor, the design team was careful to make the new system attractive to both heavy and light users, so the cycle monsters could feel free to do time-consuming research. "The philosophy here is that we would like to encourage you to use as many cycles as possible and to do research projects that can run for weeks or months," Livny explains. "But we want to protect owners, whether or not they are heavy users."

The researcher who has a job to run sends an electronic message to a special piece of Condor software called the local scheduler. The scheduler negotiates for cycles with another piece of software called the coordinator, which can be installed in any computer in the network. When the coordinator finds an idle computer, it will move the job there-if it is that researcher's turn.

Condor doesn't just run jobs in the order that it gets them. To keep big jobs from draining the pool of cycles, Livny-working with then- graduate student Matt Mutka, now on the faculty of Michigan State University-developed a priority system called the Up-Down algorithm. This system makes it possible for scientists who are running time-consuming research to coexist with people running shorter jobs. The priority that the system assigns to a scientist's project decreases as the number of cycles the scientist uses increases.

"If you are heavy user, eventually you will have low priority when competing with other users. Once you stop using the system, your priority starts to slowly go up," Livny says. "We want to protect somebody who wants to come in and run 10 to 20 hours of computing time to have a better response time than someone who is running for months and months and months."

THAT'S ONE HARD-WORKING BIRD

Researchers who use Condor gain two major advantages: they can have many tasks running at once, and they can run big projects that otherwise might be too expensive to conduct.

Without access to scavenged computing cycles, Livny explains, many of the projects run on Condor would monopolize a single workstation for months, a luxury not many researchers can afford. One UW-Madison graduate student, for example, consumed in just one month the number of cycles a single workstation would generate running around the clock for 350 days.

Although some of the workstations that Condor links are relatively slow-running at just 10 to 20 MIPS (million instructions per second) rather than the hundreds of MIPS a mainframe computer might achieve-these workstation cycles are surplus, whereas time on a mainframe is expensive.

GROOMING CONDOR

But Condor's advantages have a price: each task takes longer that it would running on a single machine. All the juggling Condor must do wastes time. Projects move from computer to computer. Projects often must wait their turn. Information must be moved in and out of electronic memory and the magnetic storage drives. And if a computer's owner returns-signaled either by tapping a key or moving the computer's mouse-the project must be interrupted and moved either to another workstation or, if no other machine is available back to its home workstation.

Often, however, the guest project hasn't finished when Condor must yield the workstation. If Condor had to restart from scratch every time a project was interrupted, many tasks-some of which can take months-would never end. To make Condor more efficient and allow big jobs to finish, the design team incorporated "checkpoints," software markers that indicate how far a job has progressed. When it places a checkpoint, Condor remembers the current status of the program, as well as any results that had been computed so far. Then, when it restarts the project somewhere else, it can pick up at the checkpoint.

The idea of checkpoints is not new, Livny says. But making checkpoints work presented a major challenge. Working outside of the UNIX operating system, Condor had to be able to remember, but not disrupt, the status of every detail of software running inside the operating system.

Originally Condor didn't place checkpoints until a workstation's owner returned. But that forced the owner to wait while Condor completed its checkpoint calculations. To speed things up, the team decided to place checkpoints periodically during the calculations. Now Condor returns to the previous checkpoint and moves the task away almost immediately. That can mean losing up to an hour's work, but, Livny says, a few lost cycles is the price of keeping workstation owners happy.

Although the design team tried to make Condor as friendly as possible some users still find it inconvenient. For example, normally a person who takes a short break while using a software application that's loaded into the computer's electronic memory will be able to resume using the application immediately. But if Condor moves in, it will displace the application. Reloading may take 10 or 15 seconds. Such delays, Livny says, can be bothersome for people who use their computers intermittently, making their machines frequent targets of Condor's scavenging excursions.

That's why the team modified Condor so that it could feed on unused machines only on a schedule that each owner approved. For some, that means their computers aren't available to the pool until an hour or two after they normally leave for the day. "We lose two or three hours of computing time for lunch and at the end of the day," Livny say, "but the fact that they join the pool means we gain 11 hours."

LEAVING THE NEST

Condor pools have spread to laboratories around the world. But because the Condor system is available for free on electronic bulletin boards, a practice computer scientists use to share new ideas, Livny doesn't know where all of them are. He has helped Condor users at the University of Michigan, Ohio State University, the Weizmann Institute in Israel, the CERN physics laboratory in Geneva, and the National High-Energy Physics Lab in the Netherlands. At some of these sites, Livny says, Condor pools comprising hundreds of machines run thousands of jobs daily.

Some UW-Madison departments are employing Condor to carry out massive computing chores. In the genetics department, for example, Condor-using machines in the computer sciences department-is helping decipher the genetic code of the bacterium Escherichia coli. This vast joint-research project requires extensive computer searches, matching newly decoded DNA patterns to a database of known protein sequences.

At UW-Madison and universities around the world, Condor supporters are explaining its advantages to scientists reluctant to relinquish complete control of their workstations. Recently, for example, Livny started working with researchers at the UW-Madison College of Engineering to find ways to use Condor for tasks currently run on supercomputers. Big projects that demand rapid results, such as sophisticated modeling of the activity inside a nuclear reactor, he says, will probably continue to justify the expense of buying supercomputer time. But others that involve highly repetitious tasks may be shifted to a new Condor network.

A FLOCK OF CONDORS

As Condor pools have multiplied, Livny's team has started work on the next logical extension of distributing computer resources. "To go beyond the boundaries of individual networks in an institution," he says, "we speak now about a flock of Condors, where you have a Condor, and a Condor, and another Condor linked."

With the flock, there are even more problems to solve. Just as each researcher in a Condor pool wants to control his or her own workstation, each research group in a flock wants to control its own Condor pool. And Condor's decisions about where to send jobs become more difficult.

The Condor pools in the flock, he says, have to be able to decide whether to keep a job in a busy pool, or fly to the next idle pool. "It's like joining a seemingly endless line in front of a teller and having a soothsayer tell you to beware of the empty teller on the next block. Are you going to leave this line and run there? Maybe everyone heard you and everyone is running there and you're better off standing here."

Livny's team is continuing to improve Condor. Some of his graduate students are working on modifying the system so that a single job could be divided and run in parallel on many workstations at once. This would mean that running jobs on Condor would actually be faster than on a single workstation. Livny, Michael Litzkow, and other team members are working with IBM on a commercial version of Condor, which would let businesses share their distributed resources. And they are continuing to fine-tune Condor to make it the perfect hunter of idle workstations.
